LG Display 34" 2560×1080 TFT LCD Panel 81PPI 300cd/m2 LM340WW1-SSA1

Name: LG Display 34quot 25601080 TFT LCD Panel 81PPI 300cdm2 LM340WW1SSA1
Brand: LG DISPLAY
Price: 1 USD

China LG Display 34" 2560×1080 TFT LCD Panel 81PPI 300cd/m2 LM340WW1-SSA1 wholesale

Brand Name : LG DISPLAY

Model Number : LM340WW1-SSA1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 1000PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM340WW1-SSA1

TEMPERATURE RANGE : 2560(RGB)×1080 (CSHD) 81PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

RESOLUTION : 2560(RGB)×1080 (CSHD) 81PPI

Lamp Type : WLED

BRIGHTNESS : 300CD/M2

SIZE : 34 inch

BRAND : LG DISPLAY

Contact Now

LG Display LM340WW1-SSA1 Application Details

Basic Detail :	Manufacturer		Model Name	LM340WW1-SSA1
	Panel Type	a-Si TFT-LCD , LCM	Another Name	LM340WW1 (SS)(A1)
	Panel Size	34 inch	Designed For
Maximum Ratings :	OP Temperature	0 ~ 50 °C	ST Temperature	-20 ~ 60 °C

LG Display LM340WW1-SSA1 Optical Details

Basic Information :	Luminance	300 cd/m² (Typ.)	Contrast Ratio	1000 : 1 (Typ.) (Transmissive)
	Good View at	Symmetry	Response Speed	14 (Typ.)(Tr+Td) (ms)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Operating Mode	AH-IPS, Normally Black, Transmissive
Color Performance :	Chromaticity	Wx:0.313; Wy:0.329	Support Color	16.7M (8-bit)
Color Performance :	Color Temperature	6485K	White Uniformity	1.33 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	77%	sRGB	100% coverage
	Adobe RGB	78% coverage	DCI-P3	80% coverage
	Rec.2020	57% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LM340WW1-SSA1 Mechanical Details

Pixel Features :	Number of Pixel	2560(RGB)×1080 [CSHD]	Arrangement	RGB Vertical Stripe
Pixel Features :	Dot Pitch(W×H)	0.105×0.310 mm	Pixel Pitch(W×H)	0.315×0.310 mm [81PPI]
Physical Size :	Active Viewing	799.8(W)×334.8(H) mm	Overall Dim.	820.8(W)×361(H) mm
Physical Size :	Bezel Opening	-	Overall Depth	11.8/19.8 (Typ./Max.) mm
Outline Features :	Form Shape	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio(W:H)	21:9	Shape Style	3-side borderless
Fixation :	Rear mounting holes (13-M3)
Other Detail :	Mass	3.56/3.74Kgs (Typ./Max.)	Surface	Antiglare, Hard coating (3H)

LG Display LM340WW1-SSA1 Interface Details

Signal Electrical :	Input Current	0.54/0.67A (Typ./Max.)		Input Voltage	10.0V (Typ.)
Signal Electrical :	Consumption	5.4/6.7W (Typ./Max.)	Signal Interface	LVDS (4 ch, 8-bit)
Interface Features :	Position		Physical Type	Connector
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
	LS Mtron	GT05P-51S-H38-E1500	1 pcs	0.5 mm	51 pins
	LS Mtron	GT05P-41S-H38-E1500	1 pcs	0.5 mm	41 pins

LG Display LM340WW1-SSA1 Lightting Details

Lamp Features:	Lamp Shape	4 strings × 2CN	Lamp Type	WLED	Position	Edge light type (Bottom side)
Lamp Features:	Exchange	-	Amount	4 strings × 2CN	Life	30K(Min.) (Hours)
Lamp Electrical :	Input Current	110/115mA (Typ./Max.)		Input Voltage	33.3+2.2V
Lamp Electrical :	Consumption	29.3/31.3W (Typ./Max.)
Interface Features :	Position		Physical Type	Connector
Interface Detail :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
Interface Detail :	JST	SM06B-SHJH(HF)	2 pcs	1.0 mm	6 pins	BLE-6PINS-CCAACC
Backlight Driver :	No
