12.3" 1920×720 167PPI 720cd/m2 TFT LCD Panel LA123WF1-SL01 89/89/89/89 (Typ.)(CR≥10)

Name: 123quot 1920720 167PPI 720cdm2 TFT LCD Panel LA123WF1SL01 89898989 TypCR10
Brand: LG DISPLAY
Price: 1 USD

China 12.3" 1920×720 167PPI 720cd/m2 TFT LCD Panel LA123WF1-SL01 89/89/89/89 (Typ.)(CR≥10) wholesale

Brand Name : LG DISPLAY

Model Number : LA123WF1-SL01

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 600PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LA123WF1-SL01

BRAND : LG DISPLAY

SIZE : 12.3INCH

BRIGHTNESS : 720CD/M2

Lamp Type : WLED

RESOLUTION : 1920(RGB)×720 167PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²)

Contact Now

LG Display LA123WF1-SL01 Application Details

Basic Information :	Brand		Model	LA123WF1-SL01
	Type	LCM a-Si TFT-LCD	Used For
	Screen Size	12.3"	Alias	-
Environment :	Storage Temp.	-40 ~~ 95 °C	Operating Temp.	-40 ~~ 85 °C
Environment :	RoHS		Vibration	3.0G (29.4 m/s²)

LG Display LA123WF1-SL01 Mechanical Details

Pixel Features :	Resolution	1920(RGB)×720	Dot Pitch(mm)	0.0507×0.1521 (H×V)
Pixel Features :	Pixel Format	RGB Vertical Stripe	Pixel Pitch(mm)	0.1521×0.1521 (H×V) [167PPI]
Mechanical Size :	Active Area(mm)	292.032(H) × 109.512(V)	Bezel Area(mm)	-
Mechanical Size :	Outline Dim.(mm)	310(H) × 128(V)	Depth(mm)	8.2/20.6 (Typ./Max.)
Outline Features :	Form Style	Flat Rectangle	Outline Shape
Outline Features :	Aspect Ratio	8:3 (H:V)	Orientation	Landscape type
Mounting :	Rear mounting Pole
Other Spec :	Weight	395/405g (Typ./Max.)	Treatment	Hard coating

LG Display LA123WF1-SL01 Optical Details

Basic Information :	Luminance(cd/m²)	720 (Typ.)	Contrast Ratio	900:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Min.)(CR≥10)	Display Mode	IPS, Normally Black, Transmissive
	Best View on	Symmetry	Response(ms)	25 (Typ.)(Tr+Td)
Color Performance :	White Coordinate	X:0.313; Y:0.329	Display Colors	16.7M (8-bit)
Color Performance :	Color Temperature	6485K	White Uniformity	1.25 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	86%	sRGB	99% coverage
	Adobe RGB	83% coverage	DCI-P3	89% coverage
	Rec.2020	65% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :	Outdoor Visibility	Sunlight Readable	Transmissivity	-

LG Display LA123WF1-SL01 Interface Details

Signal Electrical :	Voltage Supply	3.3/13.0V (Typ.)(VCC/VDD)		Current Supply	220/170mA (Typ.)(ICC/IDD)
Signal Type :	LVDS (2 ch, 8-bit)			Signal Voltage	-
Interface Features :	Position	-		Type	Connector
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :			1 pcs	60 pins

LG Display LA123WF1-SL01 Backlight Details

Backlight Features:	Shape	4 strings	Type	WLED	Position	Edge light type
Backlight Features:	Replacement	-	Quantity	11S4P	Life Time	10K(Min.) (Hours)
Lamp Electrical :	Voltage Supply	33V (Typ.)		Current Supply	90/95mA (Typ./Max.)
Lamp Electrical :	Consumption	11.88/12.54W (Typ./Max.)
Interface Features :	Position	-		Type	FPC
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :			1 pcs	20 pins	0.5 mm
Backlight Driver :	No

LG Display LA123WF1-SL01 Packing Details

Package Box :	Quantity	Weight	Box Size
Package Box :	12 pcs / box	-	478×365×244 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
