TCG121XGLPAPNN-AN20 Kyocera 12.1INCH LCM 1024×768RGB 400NITS WLED LVDS INDUSTRIAL LCD DISPLAY

Name: TCG121XGLPAPNNAN20 Kyocera 121INCH LCM 1024768RGB 400NITS WLED LVDS INDUSTRIAL LCD DISPLAY
Brand: Kyocera
Price: 1 USD

China TCG121XGLPAPNN-AN20 Kyocera 12.1INCH LCM 1024×768RGB 400NITS WLED LVDS INDUSTRIAL LCD DISPLAY wholesale

Brand Name : Kyocera

Model Number : TCG121XGLPAPNN-AN20

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW

Supply Ability : 200PCS

Delivery Time : 1-2day

Packaging Details : STANDARD PACKING

MODEL NUMBER : TCG121XGLPAPNN-AN20

BRAND : Kyocera

SIZE : 12.1INCH

RESOLUTION : 1024×768RGB

BRIGHTNESS : 400 cd/m² (Typ.)

Signal Type : LVDS (1 ch, 6/8-bit) , Connector 20 pins

Backlight : WLED , 50K hours , With LED Driver

Max. Ratings : Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C

Contact Now

Kyocera TCG121XGLPAPNN-AN20 Application Details

Basic Info :	Panel Brand		Panel Model	TCG121XGLPAPNN-AN20
	Diagonal Size	12.1"	Application
	Panel Type	a-Si TFT-LCD , LCM	Model Alias	-
Reliability :	Operating Temp.	-30 ~ 80 °C	Storage Temp.	-30 ~ 80 °C
Reliability :	RoHS State		Vibration Rating	-

Kyocera TCG121XGLPAPNN-AN20 Mechanical Details

Pixel Features :	Pixel Format	1024(RGB)×768 [XGA]	Dot Pitch	0.080×0.240 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.240×0.240 mm (H×V) [105PPI]
Mechanical Size :	Display Area	245.76×184.32 mm (H×V)	Bezel Area	249.0×187.5 mm (H×V)
Mechanical Size :	Outline Dim.	260.5×203.4 mm (H×V)	Outline Depth	10.3±0.5 mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	4:3 (H:V)	Shape Style
Holes & Brackets :	Side mounting holes (6-M3) on left, right bezel
Other Features :	Weight	670g	Surface	Antiglare

Kyocera TCG121XGLPAPNN-AN20 Optical Details

Basic Information :	Brightness	400 cd/m² (Typ.)	Contrast Ratio	750:1 (Typ.) (Transmissive)
	Viewing Angle	85/85/85/85 (Typ.)(CR≥10)	Optical Mode	AWV, Normally Black, Transmissive
	Viewing Direction	Symmetry	Response Time	18/12 (Typ.)(Tr/Td) (ms)
Color Performance :	Chromaticity	Wx:0.300; Wy:0.330	Color Numbers	262K/16.2M (6-bit / 6-bit + FRC)
Color Performance :	Color Temperature	7203K	White Uniformity	-
1931 Color Gamlt :	NTSC Ratio	51%	sRGB	71% coverage
	Adobe RGB	53% coverage	DCI-P3	53% coverage
	Rec.2020	38% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

Kyocera TCG121XGLPAPNN-AN20 Electronics Details

Frame Frequency :	60Hz
Reverse Scan :	Yes (180°)

Kyocera TCG121XGLPAPNN-AN20 Backlight Details

Back-light Features:	Lamp Shape	-	Lamp Type	WLED	Life Time	50K(Typ.) (Hours)
Back-light Features:	Replacement	-	Amount	-	Position	Edge light type
Interface Features :	Type	Connector	Position	-	Lamp Driver	With LED Driver
Interface Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Interface Detail :	JST	SM06B-SHLS-G-TF(LF)(SN)	1.0 mm	6 pins	1 pcs
Driver Electrical :	Voltage Input	12.0V (Typ.)		Current Input	480/560mA (Typ./Max.)

Kyocera TCG121XGLPAPNN-AN20 Interface Details

Signal Systerm :	LVDS (1 ch, 6/8-bit)			Logic Voltage	-
Signal Electrical :	Voltage Input	3.3V (Typ.)		Current Input	300/390mA (Typ./Max.)
Interface Features :	Type	Connector	Position	-
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Connector Detail :	I-PEX	20186-020E-11F	1.25 mm	20 pins	1 pcs	LVDS-20P1C8B-010H

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
