T-51963GD035J-MLW-AGN Kyocera 3.5INCH LCM 240×320RGB 130NITS WLED TTL INDUSTRIAL LCD DISPLAY

Name: T51963GD035JMLWAGN Kyocera 35INCH LCM 240320RGB 130NITS WLED TTL INDUSTRIAL LCD DISPLAY
Brand: Kyocera
Price: 1 USD

China T-51963GD035J-MLW-AGN Kyocera 3.5INCH LCM 240×320RGB 130NITS WLED TTL INDUSTRIAL LCD DISPLAY wholesale

Brand Name : Kyocera

Model Number : T-51963GD035J-MLW-AGN

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW

Supply Ability : 1000PCS

Delivery Time : 1-2day

Packaging Details : STANDARD PACKING

MODEL NUMBER : T-51963GD035J-MLW-AGN

BRAND : Kyocera

RESOLUTION : 240×320RGB

SIZE : 3.5INCH

BRIGHTNESS : 130 cd/m² (Typ.)

Signal Interface : CMOS (1 ch, 6-bit) , 50 pins FPC

Lamp Type : WLED , 5K hours , Without Driver

TEMPERATURE RANGE : Operating Temp.: -20 ~ 70 °C

Contact Now

OPTREX T-51963GD035J-MLW-AGN Application Details

Basic Information :	Brand		Model	T-51963GD035J-MLW-AGN
	Type	LCM a-Si TFT-LCD	Used For
	Screen Size	3.5"	Alias	-
Environment :	Storage Temp.	-30 ~~ 70 °C	Operating Temp.	-20 ~~ 70 °C
Environment :	RoHS		Vibration	-

OPTREX T-51963GD035J-MLW-AGN Mechanical Details

Pixel Features :	Resolution	240(RGB)×320, QVGA	Dot Pitch(mm)	0.0745×0.2235 (H×V)
Pixel Features :	Pixel Format	RGB Vertical Stripe	Pixel Pitch(mm)	0.2235×0.2235 (H×V) [113PPI]
Mechanical Size :	Active Area(mm)	53.64(H) × 71.52(V)	Bezel Area(mm)	-
Mechanical Size :	Outline Dim.(mm)	65(H) × 86.2(V)	Depth(mm)	4.0 (Typ.)
Outline Features :	Form Style	Flat Rectangle	Outline Shape
Outline Features :	Aspect Ratio	3:4 (H:V)	Orientation	Portrait type
Touch Panel :	Touch Points	1 point	Touch Panel	4-wire Resistive Touch
Touch Panel :	TP Controller	Without touch controller	Touch Signal	-
Other Spec :	Weight	50.0g (Max.)	Treatment	-

OPTREX T-51963GD035J-MLW-AGN Optical Details

Basic Information :	Luminance(cd/m²)	130 (Typ.)	Contrast Ratio	70:1 (Typ.) (Transmissive) 5:1 (Typ.) (Reflective)
	Viewing Angle	40/40/40/40 (Typ.)(CR≥10)	Display Mode	TN, Normally White, Transflective
	Best View on	-	Response(ms)	30/50 (Typ.)(Tr/Td)
Color Performance :	White Coordinate	X:0.320; Y:0.350	Display Colors	262K (6-bit)
Color Performance :	Color Temperature	6022K	White Uniformity	1.43 (Max.)(5 points)
Dispaly Performance :	Outdoor Visibility	Sunlight Readable	Transmissivity	-
Dispaly Performance :	3D Type	-	Reflectance	20% (Typ.)

OPTREX T-51963GD035J-MLW-AGN Electronics Details

Frame Rate :	60Hz
Reverse Scan :	Yes (U/D, L/R)
Time Controller (T-CON) :	Embedded T-CON

OPTREX T-51963GD035J-MLW-AGN Interface Details

Signal Electrical :	Voltage Supply	3.3/5.0/16.0/-12.0V (Typ.)(VDDD/VDDA/VGH/VGL)		Current Supply	1.6/8.0/0.05/0.05mA (Typ.)(IDDD/IDDA/IGH/IGL)
Signal Type :	CMOS (1 ch, 6-bit)			Signal Voltage	0≤VIL≤0.8V; 2.7V≤VIH≤3.6V
Interface Features :	Position	-		Type	FPC
Interface Detail :	Brand	Model	Quantity	Pins	Pitch	Pin Configuration
Interface Detail :			1 pcs	50 pins	0.5 mm

OPTREX T-51963GD035J-MLW-AGN Backlight Details

Backlight Features:	Shape	-	Type	WLED	Position	Edge light type
Backlight Features:	Replacement	-	Quantity	-	Life Time	5K(Min.) (Hours)
Lamp Electrical :	Voltage Supply	19.2/21.0V (Typ./Max.)		Current Supply	15/20mA (Typ./Max.)
Lamp Electrical :	Consumption	0.384W (Typ.)
Interface Features :	Position	-		Type	Included in panel signal interface
Backlight Driver :	No

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.

T-51963GD035J-MLW-AGN Kyocera 3.5INCH LCM 240×320RGB 130NITS WLED TTL INDUSTRIAL LCD DISPLAY

Product Tags:

WLED Industrial TFT Display

LCD Industrial TFT Display

T-51963GD035J-MLW-AGN Kyocera 3.5INCH LCM 240×320RGB 130NITS WLED TTL INDUSTRIAL LCD DISPLAY Images
