Mitsubishi AA121TD11 Application Details
| Basic Detail : | Manufacturer | | Model Name | AA121TD11 1 Compatible |
| Panel Type | a-Si TFT-LCD , LCM | Another Name | T-55592D121J-LW-A-ABN |
| Panel Size | 12.1 inch | Designed For | |
| Maximum Ratings : | OP Temperature | -30 ~ 80 °C | ST Temperature | -30 ~ 80 °C |
| Vibration Level | 1.0G (9.8 m/s²) | RoHS |
Mitsubishi AA121TD11 Optical Details
| Basic Information : | Luminance | 1500 cd/m² (Typ.) | Contrast Ratio | 700 : 1 (Typ.) (Transmissive) |
| Good View at | 6 o'clock | Response Speed | 4/12 (Typ.)(Tr/Td) (ms) |
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Support Color | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| Color Temperature | 6485K | White Uniformity | 1.30 (Max.)(5 points) |
| 1931 Color Gamlt : | NTSC Ratio | 40% | sRGB | 56% coverage |
| Adobe RGB | 41% coverage | DCI-P3 | 41% coverage |
| Rec.2020 | 30% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity |
Mitsubishi AA121TD11 Mechanical Details
| Pixel Features : | Number of Pixel | 1280(RGB)×800 [WXGA] | Arrangement | RGB Vertical Stripe |
| Dot Pitch(W×H) | 0.068×0.204 mm | Pixel Pitch(W×H) | 0.204×0.204 mm [124PPI] |
| Physical Size : | Active Viewing | 261.12(W)×163.2(H) mm | Overall Dim. | 283(W)×185.1(H) mm |
| Bezel Opening | 263.52(W)×165.60(H) mm | Overall Depth | 9.7±0.5 mm |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 16:10 | Shape Style | |
| Fixation : | Side mounting holes (4-M3) on left, right bezel |
| Other Detail : | Mass | 580g (Typ.) | Surface | Antiglare, Hard coating (3H) |
Mitsubishi AA121TD11 Electronics Details
| Refresh Rate : | 60Hz |
| Reverse Scan : | Yes (180°) |
| Power Consumption : | 11.2W (Typ.) |
Mitsubishi AA121TD11 Lightting Details
| Lamp Features: | Lamp Shape | 4 strings | Lamp Type | WLED | Position | Edge light type |
| Exchange | No | Amount | 4 strings | Life | 100K(Typ.) (Hours) |
| Lamp Electrical : | Input Current | 100/110mA (Typ./Max.) | Input Voltage | 24.0/28.2V (Typ./Max.) |
| Interface Features : | Position | - | Physical Type | Connector |
| Interface Detail : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| JST | SM10B-SHLS-TF(LF)(SN) | 1 pcs | 1.0 mm | 10 pins | BLE-10PINS-NNCAACCAAC |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 261.12(W)×163.2(H) mm, outline size of 283(W)×185.1(H)×10.2(D) mm, viewing area size of 263.52(W)×165.60(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 580g (Typ.). As a TN, Normally White, Transmissive LCM product, AA121TD11 can provides 1500 cd/m² display brightness 700:1 transimissive contrast ratio, 80/80/80/60 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 4/12 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit / 6-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 262K/16.7M colors, also with performance of color gamut 40% (NTSC). This product adopted 4 strings WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 100K hours, external backlight driver is additionally needed. AA121TD11 utilizes LVDS (1 ch, 6/8-bit) as it's signal inputting systerm, which connected by 20 pins Connector with power supply voltage of 3.3V (Typ.)
